Now more than ever, today’s competition quality off-road vehicles and giant scale aircraft demand uncompromised quality and performance in the never-ending race for gold. The Ultra-Premium DB961WP answers that call for increased durability, providing the Pro-Class dependability and reliability you demand, regardless of your mission. Coupling massive torque and high speed with its wide voltage range and high resolution/low deadband circuitry, the DB961WP will deliver your hobby to a new level.
Features
- Voltage Range is 4.0V - 8.4V
- Torque: 763 in./oz. @ 6V & 7.4V
- Optimized for up to 2-Cell LiPo Use
- Ultra-Performance Brushless Motor
- 32-Bit MCU Technology / 4096 Resolution
- High Resolution/Low Deadband Circuitry
- User Programmable Thermal Cutoff
- Full Programmability
- IP67 Waterproof Rating
- Smart Sense Technology for Servo Analytics
- H25T Industry Standard Output Spline
Next Generation Case Design
- Machined Aluminum
- Dual Oversized Bearings
- Hardened Steel Gear Train
- 3 Hardened Steel Pins
DB961WP Servo Specifications
| Performance Specifications | |
| Operating Voltage Range (Volts DC) | 4.0V ~ 8.4V |
| Speed (Second @ 60°) | 0.15 @ 7.4V |
| Maximum Torque Range oz. / in. | 763.81 @ 7.4V |
| Maximum Torque Range kg. / cm. | 55.0 @ 7.4V |
| Current Draw at Idle | 35mA @ 7.4V |
| No Load Operating Current Draw | 500mA @ 7.4V |
| Stall Current Draw | 6,500mA @ 7.4V |
| Dead Band Width | 1us |
| Physical Specifications | |
| Dimensions (Inches) | 1.58 x 0.79 x 1.54 in. |
| Dimensions (Metric) | 40.0 x 20.0 x 39.0 |
| Weight (Ounces) | 3.18 |
| Weight (Gram) | 90.0 |
| Circuit Type | 32bit Programable Digital |
| Motor Type | Brushless |
| Gear Material | 5 Steel Gears |
| Bearing Type | 2 Ball Bearings |
| Output Shaft (type / Ømm) | H25T |
| Case Material | Aluminum |
| Dust / Water Resistance | IP67 Rated |
| Connector Gauge (AWG) / Strand Count | 20AWG |
| Radio Control Applications | |
| Parkflyer | N / A |
| Sport Plane | N / A |
| Sailplane | N / A |
| 3D Performance | N / A |
| Scale | Giant |
| Electric Helicopter | N/A |
| Gas Helicopter | N/A |
| On Road | YES |
| Monster Truck | YES |
| Buggies | 1/8th |
| Truggies | 1/8th |
| Short Course / Truck | YES |
| Crawlers | YES |
| Sail Boat | N / A |
| Power Boat | N / A |
